3Digits in 12inch LED Digital Clock For Days Countdown Function
| PRODUCT PARAMETER |
| Format : | 888 (Days) | Color : | Red |
| Display Size : | 600mm x 1000mm | Thickness : | 100mm |
| Digit Size : | 8'' 200mm | Housing : | Iron Cabinet |
| Communication1 : | IR Remote | Communication Distance : | IR = 10M |
| Communication2 : | Wire | Communication Distance : | RS232 = 50M |
| Communication3 : | Wireless | Communication Distance : | RF433 =1000M |
| Output Voltage : | 5V | Volatge Input : | 110V ~ 240V AC |
| Brightness : | 5000cd / M2 | Working Temp : | -30℃ ~ +65℃ |
| Viewing Angle : | > 100° | Working Humidity : | 5% - 90% RH |
| Life Span : | 100,000 Hours | Waterproof : | IP65 |
Dimensions / Function
Dimension:
| Model | Timer Size | Package Dimension |
| 8'' 200mm | 300mm x 470mm x 100mm | 370mm x 540mm x 170mm |
| 10'' 254mm | 350mm x 600mm x 100mm | 410mm x 670mm x 170mm |
| 12'' 300mm | 450mm x 700mm x 100mm | 510mm x 770mm x 170mm |
| 16'' 400mm | 600mm x 1000mm x 100mm | 670mm x 1070mm x 170mm |
| 20'' 500mm | 750mm x 1100mm x 100mm | 820mm x 1170mm x 170mm |
| 24'' 600mm | 800mm x 1400mm x 100mm | 870mm x 1470mm x 170mm |
| 30'' 750mm | 1000mm x 1600mm x 100mm | 1070mm x 1670mm x 170mm |
Timer Function:
1. Display : Days (3 Digits) Countdown / Count Up
2. Count up : Count from zero to 999 days
3. Countdown : Count from 999 days to zero
Available Option:
* Timer can work by Battery .
Installation Method
For Indoor Scoreboard :
1) Bracket / Bracket with wheels
2) Hanging with Hooks and it is dangly
3) Hanging on the Wall and it is fixed on wall
4) Hanging on the pillar with anchor ear
For Outdoor Scoreboard:
1) Portal Frame
2) Hanging on the Wall and it must be fixed
3) Hanging on the pillar with anchor ear
4) Bracket / Bracket with wheels ( Only for small size )
5) Hanging into Wall and Fixed
Attention Matters:
Dissipate Heat and Drainage - Inform us the installation method in advance ,we will make
right method on scoreboard.
Maintenance - Easy to do maintance from front or back side .
Stable and stronger Method - Weatherproof
Timer Descripition
Specification :
1) Use of the environment: Outdoor and Indoor
2) Brightness: High Level Brightness
3) Height of Number Option : 6'' / 8'' / 10'' / 12'' / 16'' / 20'' / 24'' / 30'' ect.
4) Number Color Option : Red / Green / Amber / Blue / White
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display Sign Include : Numbers ,Controller , Cabinet / Frame ,Power Supply
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,5% ~ 90% relative humidity
Operation Type :
1) Controller Type : IR Remote / PVC Buttons Controller Box / Windows Software
2) Communication Type : IR / Hard - wire / Wireless Type
3) Operation Distance : 10m ~ 1200m.
4) Operation Power : Remote with Battery / Controller Box with 110v ~ 240v Power
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Tripod / With wheels / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 370mm x 540mm x 170mm
Purchase Process
1. Inquiry-Professional quotation by email or telephone. 2. Confirm the price, lead time, artwork, payment term etc. 3. Send the Performa Invoice. 4. Customer makes the payment and sends us Bank receipt. 5. Initial Production Stage-Inform the clients that we have got the payment, And will make the samples according to your request, send you photos or Samples to get your approval. After approval, we inform that we will arrange the production & inform the estimated time. 6. Middle Production-send photos to show the production line which you can see your products in . Confirm the estimated delivery time again. 7. End Production-Mass production products photos and samples will send to you for approval. You can also arrange the third party inspection if you need. 8. Finish the balance payment if the order has .Book the flight or vessel and ship the goods. Inform the tracking number or send the Documents for Customer to do Customs Clearance. 9. Order can be say “finish” when you receive the goods and satisfy with them. 10. Feedback to us about Quality, Service, Market Feedback & Suggestion. And we can do better.
Usual Questions
Q1: What should I do if my Scoreboard is not working properly?
Check the Input Power is with right Volatge. Some countries use 110V and Some Countried use 220V.
If the controller box is without Battery. That must be a power cable to connect to 110V / 220V plug.
Any other problem can contact with us and take photos for us to check .
Q2: What is the correct way to store the scoreboard ?
1. Keep out of the reach of children under 8 years.
2. Do not store in dampness and high temperature places.
3. Avoid direct sunlight.
Q3 : What about the maintaince for the scoreboard ?
2 Years Warranty .
Under the condition of not artificial damage, we will send you the new parts to replace.
