Electronic Name and Digit for 8.88 9/10 format LED Gas Price Sign with Wireless Controller box
| PRODUCT PARAMETER |
| Format : | 8.88 with 9 / 10 | Color : | Red |
| Display Size : | 900mm x 1200mm | Thickness : | 100mm |
| Digit Size : | 20'' 500mm | Housing : | Iron Cabinet |
| Communication1 : | IR Remote | Communication Distance : | IR = 10M |
| Communication2 : | Wire | Communication Distance : | RS232 = 50M |
| Communication3 : | Wireless | Communication Distance : | RF433 =1000M |
| Output Voltage : | 5V | Volatge Input : | 110V ~ 240V AC |
| Brightness : | 5000cd / M2 | Working Temp : | -30℃ ~ +65℃ |
| Viewing Angle : | > 100° | Working Humidity : | 5% - 90% RH |
| Life Span : | 100,000 Hours | Waterproof : | IP65 |
Gas Price Sign Descripition
Specification :
1) Use of the environment: Outdoor Gas Station / Service Station
2) Brightness: High Level Brightness
3) Height of Number Option : 6'' / 8'' / 10'' / 12'' / 16'' / 20'' / 24'' / 30'' ect.
4) Number Color Option : Red / Green / Amber / Blue / White
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display Sign Include : Numbers ,Controller , Cabinet / Frame ,Power Supply
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,5% ~ 90% relative humidity
Operation Type :
1) Controller Type : IR Remote / PVC Buttons Controller Box / Windows Software
2) Communication Type : IR / Hard - wire / Wireless Type
3) Operation Distance : 10m ~ 1200m.
4) Operation Power : Remote with Battery / Controller Box with 110v ~ 240v Power
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 970mm x 1270mm x 160mm ( Carton )
Other Standard Dimensions Option
| Model | Gas Price Sign Size | Package Dimension |
| 8'' 200mm | 450mm x 630mm x 100mm | 520mm x 700mm x 160mm |
| 10'' 254mm | 550mm x 950mm x 100mm | 620mm x 1020mm x 160mm |
| 12'' 300mm | 600mm x 1000mm x 100mm | 660mm x 1070mm x 160mm |
| 16'' 400mm | 800mm x 1550mm x 100mm | 870mm x 1620mm x 170mm |
| 20'' 500mm | 900mm x 1200mm x 100mm | 960mm x 1670mm x 170mm |
| 24'' 600mm | 1000mm x 2000mm x 100mm | 1070mm x 2070mm x 170mm |
| 30'' 750mm | 1300mm x 2400mm x 100mm | 1370mm x 2470mm x 170mm |
Advantage
1. We manufactured Led Product over 10 Years.Rich experience with excellent staff, first-class production
environment ,rigorous and efficient enterprise management system.
2. Customized Design Product is welcome.And MOQ can be 1 Unit.We will provide the competition price
for Various Led Products.
3. The company has a variety of test equipment to control product quality like “Light Source Analysis
System”, “High – Low Temp & Variation Chamber”, “Transportation Vibration Testing Machine”, “Splash
Water Test Equipment” .
4. Flexible Payment – Wire Transfer (T/T), Wester Union, Paypal .
5. Products all certificated, all our products have passed all test, certification can be provided if you need.
Cautions when using Scoreboard
1. Confirm the Scoreboard Input Power is 110V or 220V .110V input power are unable to use by 220V
power socket.
2. Controller box is not waterproof, please avoid to touch the water.
3. Don’t change any electronic part if there is no any professional technician.
4. Not for Children under 12Years.
5. Stored in a dry environment, avoid direct sunlight.
6. Avoid heavy objects hit the front galss board.
About Linger
1.We are a reliable and professional supplier for led board in China for 11 years. We are specialized in
dealing a wide range of led product such as led scoreboard,led gas price sign,led message sign ,led
clock,led display and other led display. Since now we have so many fixed customers from all of the
world.
2.We accept the Customized Product or MOQ is one unit. At least 95% of led scoreboard is customized
type by our design on our website. We are specialized for scoreboard controller function design
especially Australia sport of scoreboard like Australia Football board and Cricket board.
3. We supply you the most led products with the competitive price, high quality, fast delivery and best
service. We are direct seller of led board and display, you can get the most competitive price from us.
Warmly welcome to contact us, and of course, you can visit our factory if you want.
