Electronic Digital Basketball Scoreboard in Yellow Color with Waterproof Frame
| PRODUCT INFORMATION |
| Model No. : | LG-LBS-15D200Y |
| Dight Height and Color : | 8'' 200mm Height in Yellow Color |
| Display Dimension : | 3.6 ft x 3.9 ft ( 1100mm*1500mm*100mm ) |
| Operation Type : | PVC Buttons Type Controller Box / Windows Software (Wireless) |
| View Distance : | 1m ~ 300m |
| Application : | Basketball Game |
| Frame Color : | Black / other Colors |
| Printed Letters | Sticker in White Color |
| Brightness : | > 5000mcd / sqm |
| Waterproof : | Outdoor Type |
Basketball Scoreboard Descripition
Function : Display Basketball Game Score and Information.
Specification :
1) Use of the environment: Indoor or Outdoor
2) Brightness: High Level Brightness
3) Height of Characte: 8'' 200mm
4) Display Led Color : Yellow (Any other kind is Option)
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display usage: 15 Pieces digits ,8 inch height character in Yellow Color
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,0% ~ 95% relative humidity
Operation Type :
1) PVC Buttons Controller Box / Windows Software
2) Hard - wire / Wireless Type
3) Operation Distance : Max 1000Meters.
4) Controller box works by 110V ~ 240V Power (Battery is an Option)
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 1170mm x 1570mm x 160mm (Carton)
Screen Dimension : 3.6 ' x 3.9 ' x 4''
Function
Game Time :
1) 4-Digits to Display : MM : SS
2) Countdown / Count Up / Day Time is Option
3) Set time by Controller with Buttons for MIN +1 -1 , SEC +1 -1
Team Score :
1) Time Out : 1 digit display number 0 - 9
2) Fouls : 1 digit display number 0 - 9
3)Home and Away Scores : 3digits display number from 000 - 999
Period : 1 Digits display number 0 - 9
Siren : With Siren ,when time reach to 00 : 00 ,it will sound for 5''
Led Brightness : Option
SCOREBOARD FUNCTION IS CUSTOMIZED ,ANY FUNCTION IS WELCOME !
FAQ
Q1. What is your payment ?
A : We accept T/T , Wester Union , Paypal.
Q2. When can you arrange the shipment after i have placed an order ?
A : Usually about 10days after receiving Payment.
Q3. Can you accept customized ?
YES.Welcome!
Q4. Is it OK to print my logo on the product?
A : Yes. Please inform us formally before our production and confirm.
Packing and Logistics
1. Where do you load the goods?
We offer shipment by sea or by air as requested by the buyer. The sea port we are used : Shanghai Sea port The airport we are used : Shanghai Airport
2. What is the lead time ?
Usually, the lead time is 7-10 days. 3. Which logistics company do you cooperate with? Our company cooperates with COSCO, APL, CMA, CSAV, K-LINE, MSC and etc. For courier, it’s up to buyer’s option. We will give suggestion according to the time table of the steamers and their services.
Usual Questions
Q1: What should I do if my Scoreboard is not working properly?
Check the Input Power is with right Volatge. Some countries use 110V and Some Countried use 220V.
If the controller box is without Battery. That must be a power cable to connect to 110V / 220V plug.
Any other problem can contact with us and take photos for us to check .
Q2: What is the correct way to store the scoreboard ?
1. Keep out of the reach of children under 8 years.
2. Do not store in dampness and high temperature places.
3. Avoid direct sunlight.
Q3 : What about the maintaince for the scoreboard ?
2 Years Warranty .
Under the condition of not artificial damage, we will send you the new parts to replace.
