Low Volatge and Current with Shot Clock Led Electronic Scoreboard for Waterpolo
| PRODUCT INFORMATION |
| Model No. : | LG-EWS8D200R-SC2 |
| Dight Height and Color : | 8'' 200mm Height in RED Color |
| Display Dimension : | 3 ft x 4.6 ft x 4inch ( 900mm x 1400mm x 100mm ) |
| Shot Clock Height and Color : | 8'' 200mm Height in RED Color |
| Shot Clock Size : | 400mm x 450mm x 2 Pieces |
| Operation Type : | PVC Buttons Type Controller Box / Windows Software (Wireless) |
| View Distance : | 1m ~ 200m |
| Application : | Waterpolo Sports |
| Frame Color : | Black / other Colors |
| Weight : | 30kgs |
| Waterproof : | Outdoor Type |
Waterpolo Scoreboard Descripition
Function : Used for Waterpolo Sport
Specification :
1) Use of the environment: Indoor or Outdoor
2) Brightness: High Level Brightness
3) Height of Characte: 8'' 200mm
4) Display Led Color : RED Color (Any other kind is Option)
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display usage:
12 Pieces digits , 8 inch character in RED Color
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,0% ~ 95% relative humidity
Operation Type :
1) PVC Buttons Controller Box / Windows Software
2) Hard - wire / Wireless Type
3) Operation Distance : Max 1000Meters.
4) Controller box works by 110V ~ 240V Power (Battery is an Option)
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 970mm x 1470mm x 160mm ( Carton ) / 50kgs
Screen Dimension : 3 ' x 4.6 ' x 4''
Function Descripition
Waterpolo Scoreboard with a pair of low voltage pool side shot clocks ,function see below :
GAME TIME : Countdown Game Clock - 4 Digits display Minutes : Seconds
SCORES : HOME & AWAY - 2 Digits for each team show 00 - 99
PERIOD : Indicator - 1 Digit show Number 0 - 9
TIME OUT : 2Lights for each side - ON / OFF
SHOT CLOCK : Countdown Second - 2 Digits show number from 99 - 00
Siren : Include . When time is reach to 00 :00 , it will sound for 5 ''
Led Brightness Adjustment : Option
SCOREBOARD FUNCTION IS CUSTOMIZED ,ANY FUNCTION IS WELCOME !
Available Options
Wireless Remote Control AC System for use with standard numeric scoreboards
Wireless Remote Notepad PC controller for use with electronic text displays & numeric scoreboard
Mobile trolley on pneumatic wheels
Rechargeable battery power pack
Sponsor Panel Graphics
Pair of 12"/300mm LED 4-14 digit electronic team name inputs
Pair of 16"/400mm LED 4 -14 digit electronic team name
Pair of 20"/500mm LED 4 -14 digit electronic team name inputs
Pair of 24"/600mm LED 4 -14 digit electronic team name inputs
12"/300mm LED VMS text display for advertising or game info
16"/400mm LED VMS text display for advertising or game info
20"/500mm LED VMS text display for advertising or game info
24"/600mm LED VMS text display for advertising or game info
Usual Questions
Q1: What should I do if my Scoreboard is not working properly?
Check the Input Power is with right Volatge. Some countries use 110V and Some Countried use 220V.
If the controller box is without Battery. That must be a power cable to connect to 110V / 220V plug.
Any other problem can contact with us and take photos for us to check .
Q2: What is the correct way to store the scoreboard ?
1. Keep out of the reach of children under 8 years.
2. Do not store in dampness and high temperature places.
3. Avoid direct sunlight.
Q3 : What about the maintaince for the scoreboard ?
2 Years Warranty .
Under the condition of not artificial damage, we will send you the new parts to replace.
Technology Cooperation
Hardware :
1) As Final Output Equipment
2) Provide Function Of Data Collection
3) Building the Synchronous Communication Architecture
4) To be the matching Display Equipment
5) Establish Platform for Man-machine communication
6) Form a complete set of electromechanical integration equipment
Software :
1) Building the Synchronous Communication Signal
2) Provide the Outside data feedback
3) Provide the Usual Data Feedback
4) Network Support
5) Form a complete set of electromechanical integration equipment signal
Special Product Customization :
1) Special 7 Segments Digit for Size and Shape
2) Special 16 Segments Digit which is displayed Letter (A -Z)
3) Manufacture Different Size and Color for Signal instruction Light
4) Multi – Function Communication
